A real-time visual localization service built on ORB-SLAM3. It exposes a camera-driven SLAM pipeline over a local HTTP interface, enabling live pose streaming, map management, and camera calibration from any browser or REST client.

The service captures frames from a camera (USB, V4L2, or any MJPEG/RTSP URL), runs them through ORB-SLAM3, and publishes the resulting camera pose via Server-Sent Events. A web UI is served directly from the process — no separate web server needed.

Key capabilities:

• Live localization against a pre-built map, or active mapping to build a new one
• Pose streaming at ~30 fps over SSE (/api/stream/pose)
• Map management: switch between maps, create new maps, download/upload atlas files
• Camera calibration: chessboard-based calibration via the web UI, with live preview
• Floor alignment: RANSAC-based automatic floor plane detection, or manual pitch/roll adjustment

• CMake ≥ 2.8
• OpenCV ≥ 4.4
• Eigen3 ≥ 3.1
• Boost (serialization)
• DBoW2 and g2o (included in Thirdparty/)
• Sophus (included in Thirdparty/)

# Build Thirdparty libraries first (DBoW2, g2o)
cd Thirdparty/DBoW2 && mkdir -p build && cd build && cmake .. && make -j4
cd ../../../Thirdparty/g2o && mkdir -p build && cd build && cmake .. && make -j4

# Build the project
mkdir -p build && cd build
cmake ..
ninja localization_service_host   # or: make -j4 localization_service_host

# Optionally build the OSA conversion tool
ninja osa_convert

The main binary is output to localization_service/localization_service_host. The OSA tool is output to localization_service/tools/osa_convert.

You also need the ORB vocabulary file:

cd Vocabulary && tar -xf ORBvoc.txt.tar.gz

cd localization_service
./localization_service_host \
    ../Vocabulary/ORBvoc.txt \
    example.yaml \
    /dev/video0

Open http://localhost:11142 to access the web interface. Once the map looks good, download it via Atlas → Download (.osa file).

./localization_service_host \
    ../Vocabulary/ORBvoc.txt \
    example.yaml \
    /dev/video0 \
    --localize \
    --map-id 0

The orblsammer_espnode firmware turns an ESP32-S3 with an OV5640 camera and MPU-6050 IMU into a wireless sensor node. The host discovers it automatically via UDP broadcast and drives it over a single persistent TCP connection.

# Auto-discover the node
./localization_service_host \
    ../Vocabulary/ORBvoc.txt \
    example.yaml \
    espnode \
    --espnode-fps 10

# Connect directly by IP (skip discovery wait)
./localization_service_host \
    ../Vocabulary/ORBvoc.txt \
    example.yaml \
    espnode:192.168.1.42 \
    --espnode-fps 15 \
    --localize

The host sends a single-byte trigger at the configured FPS rate; the node responds with a JPEG frame. IMU data (roll/pitch/yaw + velocity) is streamed continuously at ~20 Hz between frames over the same connection. See ESP32 sensor node for hardware details.

When started with none or espnode, the service uses the ingest queue path instead of VideoCapture. See Frame ingest and Single-shot localization.

All options after the three required positional arguments are named flags:

All endpoints are served on port 11142.

/api/status response:

{
  "localizationMode": false,
  "allowMapCreation": true,
  "paused": false,
  "currentMapId": 1,
  "maps": [
    { "id": 0, "keyframes": 142, "mappoints": 3891 },
    { "id": 1, "keyframes": 67,  "mappoints": 1204 }
  ]
}

Each event is a JSON object:

{ "valid": true, "x": 0.1, "y": -0.3, "z": 0.8, "qx": 0, "qy": 0, "qz": 0, "qw": 1 }

When tracking is lost: { "valid": false }

The request body must be a raw JPEG. Optional query parameters:

Response (both variants):

{
  "queued": true,
  "tracking_state": "OK",
  "pose": { "valid": true, "x": 1.23, "y": 0.45, "z": 0.67,
            "qx": 0.0, "qy": 0.0, "qz": 0.0, "qw": 1.0 }
}

queued: false is returned when the body is empty (pose-only query). tracking_state is one of OK, RECENTLY_LOST, LOST, NOT_INITIALIZED. HTTP 503 is returned when the ingest queue is full — the client should drop the frame and retry.

Everything else under / is served from localization_service/html/. The default page (/) loads index.html.

While the service is running, commands can be typed directly in the terminal:

Camera intrinsics and the active map can be set at runtime through the web interface — a correctly tuned YAML file is not required to get started.

• Calibration: use the Calibration page to capture chessboard frames and compute intrinsics, or enter known values directly via /api/calibrate/apply. The result is applied to the running SLAM system immediately.
• Map: upload a previously saved .osa atlas file via Atlas → Upload, or download the current map via Atlas → Download to reuse across sessions.

A minimal YAML file is still needed to launch the process (it sets sensor type, image size, and ORB feature count). See localization_service/example.yaml for a starting template. The format follows the ORB-SLAM3 settings specification — refer to README_ORB_SLAM.md for full documentation.

The following keys extend the standard ORB-SLAM3 settings file with project-specific behaviour.

The merge pipeline is cascaded: a candidate must pass every stage in order. The Sim3 and projection stages remain strict even when the BoW thresholds are lowered, so false-positive merges are unlikely. Additionally, a merge is only triggered after 3 consecutive keyframes all pass the full pipeline.

A device that needs a one-off position fix (rather than continuous tracking) can use the frame ingest endpoint without running a local camera loop.

Start the service in localization-only mode with none as the camera source:

./localization_service/localization_service_host \
    ../Vocabulary/ORBvoc.txt \
    example.yaml \
    none \
    --localize \
    --map-id 0

Then from the device (Python example, requires opencv-python and requests):

import time
import cv2
import requests

SERVER = "http://localization-host:11142/api/frame"
session = requests.Session()

def get_pose(frame) -> dict | None:
    """Submit one frame and return the pose once tracking confirms it."""
    _, buf = cv2.imencode(".jpg", frame)
    # Submit the frame; response contains the pose from the previous frame.
    r = session.post(SERVER, data=buf.tobytes(),
                     params={"ts": f"{time.monotonic()*1000:.3f}"},
                     headers={"Content-Type": "image/jpeg"}, timeout=1.0)
    if r.status_code != 200:
        return None

    # Poll with an empty body until this frame has been processed.
    for _ in range(20):
        r = session.post(SERVER, data=b"", timeout=1.0)
        data = r.json()
        if data["tracking_state"] == "OK" and data["pose"]["valid"]:
            return data["pose"]
        time.sleep(0.05)
    return None

cap = cv2.VideoCapture(0)
ret, frame = cap.read()
pose = get_pose(frame)
if pose:
    print(f"Position: x={pose['x']:.3f}  y={pose['y']:.3f}  z={pose['z']:.3f}")

The empty-body POST is a lightweight pose-only query — it does not submit a frame to the tracker. The poll loop typically converges in 1–3 iterations (50–150 ms) once the system is already localized.

A ready-to-run streaming version that forwards a full camera feed is provided in tools/send_camera_frames.py.

The localization_service/tools/ directory contains tools for working with .osa map files outside of a live SLAM session.

Converts an .osa atlas to/from a portable JSON representation. Useful for inspecting, editing, or programmatically constructing maps.

# Serialize an atlas to JSON (binary blobs are base64-encoded)
./localization_service/tools/osa_convert dump  Session.osa  atlas.json

# Pack the JSON back into a loadable .osa file
./localization_service/tools/osa_convert pack  atlas.json   output.osa

The JSON contains every serialized field: vocabulary metadata, all Maps, KeyFrames (pose, descriptors, keypoints, BoW vectors, covisibility, spanning tree, IMU state), and MapPoints (world position, descriptor, observations, depth limits). Full round-trips are lossless: 284 KFs / 7271 MPs dump and pack back identically.

Build with:

cd build && ninja osa_convert

A Python module that wraps osa_convert to provide high-level read/write access to OSA atlas files from Python scripts.

from localization_service.tools.osa_file import OsaAtlas

atlas = OsaAtlas.load("Session.osa")
m = atlas.maps[0]

# NumPy arrays for all 3D data
pts    = m.world_points()      # (N, 3) float32 — MapPoint world coordinates
cams   = m.camera_centers()    # (K, 3) float32 — KeyFrame camera positions

# Access individual elements
kf = m.keyframes[0]
print(kf.timestamp, kf.fx, kf.descriptors.shape)   # e.g. (1506, 32)

mp = m.mappoints[0]
print(mp.world_pos, mp.descriptor.shape)            # e.g. (32,)

# Round-trip save
atlas.save("output.osa")

# Create a blank atlas for building a map from scratch
atlas = OsaAtlas.new("ORBvoc.txt", "checksum")

These tools are the foundation for an offline atlas-construction pipeline that can build higher-quality maps from a directory of images using techniques not available in the real-time tracker.

localization_service/
  src/
    localization_service_host.cc  — main(): SLAM init, tracking loop
    espnode_source.cc             — ESP32 TCP session, IMU buffer, frame ingest
    slam_state.cc                 — shared atomic flags and pose state
    calibration_manager.cc        — chessboard calibration logic
    web_server.cc                 — HTTP server and all route handlers
    ingest_queue.cc               — IngestQueue push/pop implementation
  include/localization_service/
    args.h                        — ServiceArgs struct, parseArgs() (all CLI flags)
    config.h                      — port define (11142) and tuning constants
    slam_state.h                  — LifecycleFlags, PoseState
    ingest_queue.h                — IngestFrame, IngestQueue (frame push API)
    espnode_source.h              — ImuSample, ImuBuffer, EspnodeSource
    calibration_manager.h         — CalibrationManager
    web_server.h                  — WebServer
  html/
    index.html                    — main web UI
    viewer.html                   — pose and map viewer
    calibration.html              — calibration assistant
  tools/
    osa_convert.cc                — C++ source for OSA ↔ JSON converter
    osa_convert                   — built binary (OSA ↔ JSON CLI)
    osa_file.py                   — Python module for reading/writing OSA files
    tello_camera_server.py        — relay server for Tello drone camera
    send_camera_frames.py         — forward a local camera to the frame ingest API
    record_frames.py              — record frames to disk for offline processing
    replay_frames.py              — replay recorded frames into the ingest API
  example.yaml                    — sample camera configuration

Thirdparty/orblsammer_espnode/
  src/
    xostudio_hud.ino              — PlatformIO firmware (persistent TCP + HTTP IMU)
    test_tcp_hud.py               — Python test client (discovery, triggers, IMU stream)
  platformio.ini                  — PlatformIO build config (freenove_esp32_s3_wroom)

The ESP32-S3 firmware in Thirdparty/orblsammer_espnode/ implements a lightweight sensor node that streams camera frames and IMU data over WiFi.

All packets share a 9-byte packed little-endian header:

uint8_t  packet_type   // 0x01=IMAGE  0x02=IMU  0x03=TRIGGER(host→device)
uint32_t frame_time    // ESP32 millis()
uint32_t total_size    // payload byte count

IMU payload: N × 6 × float32 — roll, pitch, yaw (radians), vx, vy, vz (mm/s).

The host drives the session:

• Trigger (0x03, 1 byte, no header) — host → ESP32 to request one JPEG frame. At most one trigger is in-flight at a time; the next is held until the IMAGE response arrives.
• IMU stream — ESP32 pushes accumulated IMU frames every 50 ms automatically, independent of triggers.

pio run -t upload          # compile and flash via PlatformIO
pio device monitor         # serial console at 115200 baud

WiFi credentials can be provisioned without recompiling via the serial console:

> setwifi
Enter SSID:
> MyNetwork
Enter password:
> ••••••••
Saved SSID 'MyNetwork' to /config.txt
Reconnecting...
Connected. IP: 192.168.1.42

Other serial commands: status (print WiFi/SD/TCP state), help.

Alternatively, write credentials to /config.txt on the SD card directly (line 1 = SSID, line 2 = password).

python Thirdparty/orblsammer_espnode/src/test_tcp_hud.py        # 5 fps (default)
python Thirdparty/orblsammer_espnode/src/test_tcp_hud.py 15     # 15 fps

The test client auto-discovers the node via UDP, opens a persistent TCP connection, sends triggers at the configured FPS, and displays incoming frames and IMU readings.

This service is built on top of ORB-SLAM3, a feature-based monocular/stereo/RGB-D SLAM system developed at the University of Zaragoza. See README_ORB_SLAM.md for the original documentation and ORB-SLAM3 paper for the academic reference.

Modifications to the ORB-SLAM3 core:

• Pangolin visualizer made optional (no display required)
• ForceRelocalization(), SwitchToMap(), and SetAllowMapCreation() APIs added
• ChangeCalibration() API added for runtime intrinsics updates
• KeyFrameDatabase scoped correctly per-map to fix cross-map relocalization
• New-map creation on tracking loss is now optional and togglable at runtime; when disabled the system continuously retries relocalization against the existing map
• Loop closing enabled by default; merge detection thresholds are configurable via YAML to handle monocular environments with sparse cross-map BoW overlap
• Fixed an infinite-loop bug in KeyFrameDatabase::DetectNBestCandidates triggered by bad keyframes mid-iteration
